Full Toyota Land Cruiser
RESURRECTION
Let Land Cruiser Heaven revive your Land Cruiser with a new outlook on life offering a complete body on Resurrection
Our Resurrection
Process
- Vehicle is picked up or delivered to our location.
- A complete 100 point inspection is performed to get an in-depth idea of current vehicle condition.
- The Resurrection process is then divided into 5 phases:
Engine Mechanical
Engine is base lined completely utilizing all Original OEM Toyota Parts. This includes all new seals, gaskets, o-rings, belts, vacuum hoses, filters, tensioners, idler pulley, ignition cables, spark plugs, distributor cap and rotor. The and induction and injection systems are serviced thoroughly. Engine oil will be replaced with Synthetic oil.
The cooling system also gets base lined with new heater rubber hoses, heater valve, new fan clutch, thermostat, and water pump, along with a complete coolant flush. Coolant system is then filled with Toyota Red Antifreeze/Coolant.
The power steering system will get a new power steering pump, and new low pressure hoses. A full power steering system oil flush is also performed.
The inspection report will dictate current state of the engine and what needs to be tackled. Based on the compression tests will dictate if engine will require more work.
Drive train / Suspension / Brakes / Steering
Drive train
Complete front knuckle rebuilt with new seals, gaskets, bearings and grease. Rear hub gets rebuilt with new seals, gaskets, and bearings. Axles/transfer case/automatic transmission are drained of old oil, flushed and new synthetic oil is used.
Brakes
Brake system is serviced with new rotors, pads, calipers all around. Rear drums are rebuilt with new hardware and shoes as well as parking brake adjusted. A complete brake flush and bleeding is then performed and new synthetic brake fluid is added.
Suspension
Old suspension is removed and a complete new Dobinson suspension is installed.
Based on the customers needs a stock height or an upgraded lift suspension is used.
All control arm bushings are replaced.
Steering
All steering tie rods are replaced and vehicle is aligned
Undercarriage Protection
Success is in the preparation. Undercarriage is steam cleaned and pressure washed removing all grease, oil, dirt and grime. It is then cleaned by hand and any exposed surface rust will be wire wheeled. Axles are removed from the frame and cleaned individually.
Undercarriage is then treated with a chemical that converts rust back to a metal. 24 hours later, the undercarriage is once again pressure washed and let air dry for 24-48 hours. Undercarriage and axles are then sprayed with 3 coats of POR15. Paint is then allowed to cured for 48 hours before reassembly of the axles onto the frame.
Interior
Interior is then completely disassembled to the bare cab. Carpet will get steam cleaned, all panels are cleaned. Any missing or damaged parts will get sourced or replaced. Sound deadening is then added to the floor, doors and roof. Carpet is then reinstalled. All seats are redone with Land Cruiser Heaven leather along with new front cushions. Steering wheel is leather wrapped.
Audio is upgraded with a Double Din Bluetooth CD radio with new all around 6.5" speakers. A reverse camera is also added.
The interior is refreshed with a complete LED light upgrade.
Exterior
Vehicle will then undergo a complete paint refresh. Any worn or damaged weatherstripping/lights/etc will be replaced. All windows, moldings, door handles, lights, bumpers, mirrors are removed. Any dings, dents or rust is repaired. Vehicle is then prepped and painted the same original color. All emblems are replaced.
Discuss your Land Cruiser resurrection
Before and After
AFTER
BEFORE
AFTER
BEFORE
“Hello, my name is Frank and I have a Land Cruiser problem!” #landcruiserheaven
Another FJ40 restoration arriving at Land Cruiser Heaven, this one all the way from Connecticut. #landcruiserheaven #landcruiser40 #fj40 #fj40landcruiser #40serieslandcruiser #40series
Finishing touches on a customer’s 100 series resurrection. What a transformation!!!! We did a complete full paint job, all new OEM carpet and LCH leather seats. On the outside 2” OME suspension with BFG KO2s and an ARB front bumper and Front Runner rack. #landcruiserheaven #landcruiser100 #100serieslandcruiser #100series
80 series frame undercoating protection in-progress still have a few spots to clean up and retouch. When we are done she will be ready for a lot more winters. Edit: this is actual chassis paint(por15) not the rubberized undercoating crap out there. #landcruiserheaven #ih8rust
Land Cruiser Heaven open house this Saturday November 21 @10am. Come on by and say hello!!!! #landcruiserheaven
Walk around video of a customer’s 2013 200 series sporting @dobinsonsusa front bumper, zenith driving lights and suspension and @arb4x4 rear bumper. Looks amazing!!! #landcruiserheaven #200series #200serieslandcruiser #landcruiser200 #landcruiser200series #dobinsons4x4 #arb
200 series ready to handle Its next assignment !! This beast is headed down to Haiti where the @dobinsonsusa front bumper and suspension will protect it from all different types of terrain and situations. What a transformation. If only they came this way from factory. #200series #landcruiserheaven #200serieslandcruiser #landcruiser200
Which one would you pick??? FZJ73 or an FJ43???? #landcruiserheaven #landcruiser #fzj73 #serie70 #fj43 #landcruiser40 #40series #serie40 #40serieslandcruiser
1FZ-FE FJ40 with H151f 5 speed getting the final touches before assembly. Loving the custom painted nebula green valve cover!!!! #landcruiserheaven #landcruiser40 #fj40 #fj40landcruiser #1fz #40serieslandcruiser #40series #industriacolombiana #orgullocolombiano
When restoring old Land Cruisers you may encounter issues in finding good usable panels to replace old worn ones. In this particular case, 55 series panels aren’t available so we made our own outer door skins. Another new product for our Land Cruiser replacement panel offering!!
#landcruiserheaven #landcruiser #ironpig #fj55series #fj55 #fj55landcruiser #industriacolombiana #orgullocolombiano
